Industrial Robot Welding Rotating Positioner Rotator

Welding positioner normally composed by worktable slewing mechanism and turnover mechanism, which let the work piece that fixed on the worktable in the desired welding or fitting angle by worktable's lifting, turnover and slewing. And the worktable's slewing is frequency inverter stepless speed regulation to achieve the satisfactory welding speed.

The welding positioner series are side tipping type, head and tail rotation type, head and tail lifting rotation type, head and tail inclined type and double rotation type, etc.

It's can match with welding manipulator to form into automatic special welding machine, and it's also match with robot peripheral equipment and robot to realize welding automation. And we also can make customized welding positioner according to clients' different work piece and technological requirements.

Main Features

1) Simple structure,easy in installation and maintation.

2) Adopting advanced world famous brand components in electric parts and operation parts.

3) Worktable diameter from 300mm-2500mm to match different workpieces.

4) High load capacity from 100kg-60000kg.

5) Flexible tilting degree 0-120° to offer most suitable welding angle for workpiece.

6)Dynamic way:hydraulic

Specification
